性能特點 |
該生產線是將一定寬的金屬卷料薄板在板寬方向縱剪成多條所需寬度的帶材并進行成品工件的卷取的成套設備。 由開卷機、對中裝置、縱剪主機、阻尼預分料、收卷機、電氣控制控制系統等組成。 通過更換與排列不同規格的刀片隔套或移動刀座,可縱剪成不同寬度成品工件。 可根據客戶的需求要及生產線的工藝與配置實際需要,另外選配上料小車、壓引裝置、夾送裝置、粗校機、 料頭剪、過渡臺、廢邊卷取裝置、卸料小車、液壓與氣動控制系統等 | |
Features: |
corresponding width of metal work, and recoil the finished working piece. It consists of uncoiler, centering device, slitting machine, pre-material damping, recoiler, electric control system etc. Through change and arrange of the different specification blade spacer This line is a complete equipment for slitting to strip by or moving blade seat, can slit to different width working piece. Can according to customer* s request or need of production to choose optional feeding car, pressing device, pinch device, rough level machine, head-cutter, transition table, waste recoil device, unloading car, hydraulic and electrical control system etc. | |
|
|
|
主要技術參數 Specifications |
項目 Name |
單位 Unit |
可選擇范圍 Optional range |
加工板厚 Plate thickness |
mm |
0.3-1.0 0.4-1.5 0.5-2.0 |
標準板寬 Standard width |
mm |
600 1000 1300 1600 |
開卷機承重 Uncoiled weight |
T |
3-15 |
縱剪寬度精度 Slitting width precision |
mm |
±0.05-0.1 |
最多分條數 Max, slitting number |
pcs |
5-15 |
機組最高線速度 Highest line speed |
m/min |
30-60 |
機組總功率 Total power |
Kw |
40-120 | | |
|
本表所列參數,不作為產品檢驗依據,僅供產品選型參考。如出現與產品實際數據有不一致處,應遵照說明書或雙方的技術協議約定。 |
The data in file not as inspection evidence, just reference for model chosen. If any difference with actual data, please refer to manual or technical agreement by both parties. | |
