| 性能特點 |
| 本設備用于不銹鋼、鍍鋅板、冷軋板卷料的開卷、校平、剪切、收卷作業，自動程度高、生產效率高。全線電 氣控制整機聯動，加工精度高。整條生產線機械、電氣、液壓、氣動自動化控制一體化，從開卷、校平、縱剪、 橫剪、收卷實行同步控制。整套設備考慮到所加工材料的表面要求較高，設計的各種過橋托輥輸送裝置，表面采 用特殊工藝，不會造成板料壓痕、碰傷、劃傷、折邊、咬邊等現象。 | |
| Features: |
| This line is for uncoiling, leveling, slitting, cut-to-length, recoil of stainless steel, galvanized sheet and cold coils. High automatic working and efficiency, the whole line linked-control by electric, high processing precision. And whole line integrated of mechanical, electrical, hydraulic, pneumatic control, synchronized uncoiling, leveling, slitting, cross-cutting and recoiling. By consider of high surface request, the designed bridges* support roller transport device, all surface adopt special art, will not occur indentation, bumps, scratches, folding and undercut. | |
|
 |
|
 |
|
| 主要技術參數 Specifications |
| 項目 Name |
單位 Unit |
可選擇范圍 Optional range |
| 加工板厚 Plate thickness |
mm |
0.3-1.5 0.4-2.0 0.5-3.0 |
| 標準板寬 Standard width |
mm |
1300 1600 |
| 開卷機承重 Uncoiled weight |
T |
6-15 |
| 縱剪寬度精度 Slitting width precision |
mm |
±0.05-0.1 |
| 最多分條數 Max, slitting number |
pcs |
5-20 |
| 收卷內徑 Recoil inner dia. |
mm |
508、610 |
| 收卷重量 Recoil weight |
T |
6-15 |
| 定尺精度 Cutting length precision |
mm/2m |
±0.5-1.5 |
| 定長范圍 Cutting length range |
mm |
500-4000 |
| 機組最高線速度 Highest line speed |
m/min |
20-60 |
| 機組總功率 Total power |
Kw |
100-300 | | |
|
| 本表所列參數，不作為產品檢驗依據，僅供產品選型參考。如出現與產品實際數據有不一致處，應遵照說明書或雙方的技術協議約定。 |
| The data in file not as inspection evidence, just reference for model chosen. If any difference with actual data, please refer to manual or technical agreement by both parties. | |
