| 性能特點 |
在薄板橫剪線的基礎上，增加縱剪功能，工件經縱剪后再定長撗剪；如果不需縱剪，抬起縱剪上刀軸，可作為
普通橫剪線使用。特別適合于汽車、電氣、制罐等行業。
由上料小車、開卷機、引頭裝置、牽引夾送及校平、緩沖活套、對中裝置、定長送料-縱剪主機、剪板機、輸 送出料、落料裝置等組成。
可另外選配活套后面的二次校平及主機主機后面的廢邊卷取裝置。 | |
| Features: |
Add slitting function on the basic of cut-to-length line for thin plate, fixed length crossing cut after slitting; lift the slit blade shaft if no need slitting, it can use as a cross-cutting line. It is suitable for industries such as car, electronic, jar-making etc,
It consists of feeding car, uncoiler, traction device, strip feeding and leveling, buffer loop, centering device, cut-to-length feeding, slitting machine, shearing machine, transport output, discharging device etc.
Can according to customer’ s request to choose optional second level machine and wasted-recoil device. | |
|
 |
|
 |
|
| 主要技術參數 Specifications |
| 項目 Name |
單位 Unit |
可選擇范圍 Optional range |
| 加工板厚 Plate thickness |
mm |
0.3-1.5 0.4-2.0 0.5-3.0 |
| 標準板寬 Standard width |
mm |
1300 1600 |
| 開卷機承重 Uncoiled weight |
T |
6-15 |
| 縱剪寬度精度 Slitting width precision |
mm |
±0.05-0.1 |
| 最多分條數 Max, slitting number |
pcs |
5-20 |
| 定尺精度 Cutting length precision |
mm/2m |
±0.5-1.5 |
| 定長范圍 Cutting length range |
mm |
500-4000 |
| 機組最高線速度 Highest line speed |
m/min |
20-60 |
| 機組總功率 Total power |
Kw |
60-150 | | |
|
| 本表所列參數，不作為產品檢驗依據，僅供產品選型參考。如出現與產品實際數據有不一致處，應遵照說明書或雙方的技術協議約定。 |
| The data in file not as inspection evidence, just reference for model chosen. If any difference with actual data, please refer to manual or technical agreement by both parties. | |
